Description
The EBMX XUB-80 V1 motor is now on a major sale!
With the EBMX XUB-80 V2 out in the market we have a few V1's left so we are putting a huge sale on them! Now is your chance to grab a new XUB 80 for as extremely cheap!
This motor was used in both European World Cup, and American World Championship E-Moto Racing! See it in action below!
Product Info
The EBMX XLB-80 motor is a performance powerhouse, featuring an 80mm stator for maximum power output, far exceeding the XLB-60. With a 40KW rating, this motor is engineered to handle heat and intense riding conditions, thanks to 180C-rated windings and U42H magnets.
Designed with a custom IPM rotor, the XLB-80 delivers precision performance with an industry-leading 1mm rotor air gap, revving up to 12,000 RPM. Encoder-based motor control ensures superior low-end torque and smoother power delivery for an unmatched riding experience.
Whether you're on the track, street, or trails, the XLB-80 is built to stay cool in race conditions, allowing you to focus on your ride without worrying about motor temperatures.
Features
40KW Power: Extreme performance, designed to handle heat and high-stress environments.
Custom IPM Rotor: 1mm air gap, revving to 12,000 RPM for exceptional power delivery.
Encoder-Based Control: Precise, smooth power with enhanced low-end torque, surpassing traditional hall sensors.
Race-Ready Cooling: Built to stay cool under intense riding conditions.
Optimized for X-9000 Controller: Seamless integration with the EBMX X-9000 and adaptable to other controllers with custom tuning.
Specs:
Peak Power: 40,000W
Voltage Range: 48V – 104V
Max Torque: 65Nm
Max Stable Rotor RPM: 12,000 RPM
Max Efficiency: 94%
Motor Configuration: 10 poles and 12 slots
Winding Type: Dual Y parallel connection
Stator and Rotor Stack Thickness: 80mm
Sensing Method: NJDC 605 Encoder
KV Value: 85-90KV
Cooling:
Air cooled: 15.5KW (28 minutes), 28KW (2 min 20 sec)
